| 1. |
Reed Space : |
30” to 300” |
| 2. |
Reed Type : |
Fast / Loose |
| 3. |
Type Hand Side : |
Right / Left |
| 4. |
Frame : |
The complete frame of loom is fitted with
the dowel pin at different joints of binders, crank bushes
and tappet bushes in order to facilitate foolproof align-meant
while erection of the loom. |
| 5. |
Crank Shaft : |
50mm machine forged and grinded edges provided
with cast-iron / gunmetal bushes / self-lubricating bushes
(optional). Extra middle support provided for rigidity
over 60” reed space loom |
| 6. |
Crank Arm : |
Made from cast iron / gunmetal bushes /
self-lubricating bushes and fitted with gunmetal / self
lubricated bushes (optional) and reinforced by steel strapping |
| 7. |
Tappet Shaft : |
Superior quality tested I.S. standard bright
bar moving on cast iron / gunmetal bushes / self-lubricating
bushes and fitted with gunmetal / self lubricated bushes
(optional) fitted brakes. |
| 8. |
Gears : |
Hob-cut helical gears to give smooth and
noiseless working & uniform quality of fabrics. Double
drive for loom above 84” reed space |
| 9. |
Picking : |
Under-picking system having chilled picking
nose and picking bowl perfectly matched and made up of
special quality metal to give longer life. |
| 10. |
Shedding : |
Twill / Twin / Dobby / Jacquard |
| 11. |
Beating : |
Slay is carefully made from selected good
quality of seasoned teak wood & shisham wood. Race board
fitted with polished slay cap is incorporated in the loom
which ensures suitable flight of the shuttle and correct
beating. |
| 12. |
Shuttle Box : |
1x1, 1x2, 2x2, 2x4, 4x4, Pick-n-Pick |
| 13. |
Take Up : |
Seven wheel take motion |
| 14. |
Let Off : |
Negative / Semi Positive / Positive |
| 15. |
On Request : |
Extra beam attachment for special fabrics
Push button system driven by the individual motor drive
Weft stop & warp stop motion |
